Introduction
TOTPVault
TOTPVault is a secure hardware vault for storing TOTP codes for two-factor authentication. It is compatible with websites and applications which support authenticators such as Google Authenticator or Authy.
For a detailed look at the hardware components, see the Hardware Overview.
Websites Tested
TOTPVault should work on almost all TOTP-based authentication sites. The list below just shows which ones have been validated to be working
| Website | Supported |
|---|---|
| Y | |
| Digital Ocean | |
| Amazon | |
| Microsoft | |
| Paypal | |
| eBay | |
| Cloudflare | |
| Dropbox | |
| Github | |
| Gitlab | |
| Protonmail |
FAQ
Why choose ESP32-C3 for the microcontroller?
The ESP32 chips have strong hardware security features such as HWRNG, encryption/hashing support, secure boot, and encrypted flash.
Other chips have some or all of these features, however the ESP32-C3 is PSA-L1 certified, has good support for Rust firmware, and is affordable.
The ESP32 has Wifi/Bluetooth, does this device use either?
No, there is no antenna on the board and the Wifi/Bluetooth stack is disabled in the firmware.
If somebody steals my device, can they generate TOTP codes for my accounts?
No, as long as your password is strong they cannot unlock the vault and generate codes.
Troubleshooting
Device does not show up
Try reinserting the device and look for a USB device with the VID 0x1A86 and PID 0x55D3.
You can run dev-info -v which will print verbose output as to how the device is selected. It is possible another device exists with the same VID/PID in which case use -p to specify the path to the exact device
"unexpected end of file" Error
Unable to get device status from: /dev/tty.usbmodem59090561791
Error = IO error while reading data: unexpected end of file
The vault is taking a while to perform operations, increase the timeout in the user application with --timeout
